Description
This Frigidaire Gallery 24-inch built-in dishwasher features multiple-cycle options, a quick wash cycle and the SpaceWise® organization system which offers adjustable racks and a large silverware basket that provides a place for virtually anything.
Features
ORBITCLEAN® WASH SYSTEM
Exclusive OrbitClean® Spray Arm provides 4 times better water coverage for an excellent clean. And AquaSurge™ Technology adjusts washing pressure based on washing needs.
ADJUSTABLE UPPER RACK
Adjustable upper rack adjust up or down to fit tall or odd shaped items.
AQUASURGE™ TECHNOLOGY
Allows you to adjust washing pressure based on your needs.
DISHSENSE™ TECHNOLOGY
Automatically adjusts the cycle time based on how much cleaning your dishes need.
EFFORTLESSDRY™ SYSTEM
Move your dishes straight to your cabinets with our EffortlessDry™ System. Towel drying becomes a thing of the past.
ENERGY STAR®
Maximize your energy and dollar savings with ENERGY STAR® Certified Appliances.
HIGH TEMPERATURE WASH
MOST ADAPTABLE DELAY START
1-24-hour options
MULTIPLE-CYCLE OPTION
Features easy-to-use cleaning cycle options including Top Rack, Rinse Only and Heavy Wash.
TALL-TUB DESIGN
Large capacity, tall-tub dishwasher fits up to 12 place settings so you can wash more at once.
SAHARADRY™
With SaharaDry™, there's no need to towel-dry before putting dishes away.
Additional Features
BUILT WITH AMERICAN PRIDE
Appliances that are high-performing, more accessible, and more innovative than ever—designed, built, and engineered in the U.S.A.
EXPRESS-SELECT® CONTROLS
Easily select options with the touch of a button.
GREYSTONE, POLYMER TUB
Supports the drying process, keeping dishes dry the first time.
Specifications
General
Type
Built-In
Color
White
Manufacturer Color
White
Place Settings
12
Tub Material
Plastic
Silence Rating
52 dB
Cycle Information
Number of Cycles
8
Wash Cycles
• PowerPlus® (heavy)
• Normal
• Quick wash (34-Min.)
• Favorite
• China crystal
• Rinse only
• Energy saver plus
• Upper rack wash only
• Normal
• Quick wash (34-Min.)
• Favorite
• China crystal
• Rinse only
• Energy saver plus
• Upper rack wash only
Options
• Heat/No heat dry
• Hi-temp wash
• NSF® certified sanitize rinse
• Hi-temp wash
• NSF® certified sanitize rinse
Features
Technologies
• GraniteGrey™ plastic tub
• OrbitClean® wash system
• SaharaDry™ technology
• Fully-integrated Express-Select® control
• SilentDesign™ 1
• Nylon TufRacks™
• DishSense™ technology
• AquaSurge™ technology
• OrbitClean® wash system
• SaharaDry™ technology
• Fully-integrated Express-Select® control
• SilentDesign™ 1
• Nylon TufRacks™
• DishSense™ technology
• AquaSurge™ technology
Delay Start Information
1-24 Hours
Delay Start
Yes
3rd Rack System
No
Control Lock
Yes
Cutlery Tray
No
Filtration System
Yes
Silverware Basket
Yes
Wi-Fi
No
Additional Information
• Digital display
• Door latch/stay-put door hinge design
• Low rinse-aid indicator light
• 5 wash levels
• 3 wash speeds
• Removable filter trap
• Soft food disposer
• Supreme rack design
• 2 cup shelves
• Adjustable rack
• 3-piece split SpaceWise® silverware basket
• 2 full rows fold-down tines
• 2 small items cover
• Integral air gap on supply
• Water usage (gallons): 4.9 - 8.5
• Water pressure (PSI): 20 - 120
• Door latch/stay-put door hinge design
• Low rinse-aid indicator light
• 5 wash levels
• 3 wash speeds
• Removable filter trap
• Soft food disposer
• Supreme rack design
• 2 cup shelves
• Adjustable rack
• 3-piece split SpaceWise® silverware basket
• 2 full rows fold-down tines
• 2 small items cover
• Integral air gap on supply
• Water usage (gallons): 4.9 - 8.5
• Water pressure (PSI): 20 - 120
Electrical Information
Information
• 120V
• 60Hz
• 60Hz
Certifications and Approvals
Energy Star Certified
Yes
NSF® Certified
Yes
ADA Compliant
No
Dimensions
Class Width
24"
Width
24 inch(es) / 60.96 cm
Height (Min.)
33.5 inch(es) / 85.09 cm
Depth (Without Handle)
25 inch(es) / 63.5 cm
Additional Dimensions
• Depth with door open 90°: 49-1/4"
• Cut-Out depth: 24"
• Cut-Out height: 35"
• Cut-Out width: 24"
• Cut-Out depth: 24"
• Cut-Out height: 35"
• Cut-Out width: 24"
Shipping Dimensions
Weight
83 lb(s) / 37.65 kg
Warranty
Warranty
Limited 1 Year Parts and Labor.
UPC
UPC#
0-12505-11403-8
